HF {5 Ikoreshwa cyane mugutegura ibipapuro bya bisi ya bisi, umuringa uhuza aluminiyumu, guhuza bateri, hamwe nibindi bikoresho byayobora.
Imashini ikomatanya kugenzura PLC, gukoraho ecran, gukora servo - kugaburira, hamwe na bine - ibikoresho bya sitasiyo utabishaka. Gukata uburebure, ingano y'ibyiciro, n'umuvuduko wo gukora birashobora gushirwaho biturutse kuri ecran ya ecran. Imizingo igera kuri ine irashobora gutwarwa no gutunganyirizwa murwego rumwe rwo guca, bigatuma imashini ibera umusaruro wibyiciro birimo imizingo myinshi ya fayili imwe cyangwa isa.
Ugereranije no gupima intoki no gukata cyangwa gutunganya umuzingo umwe icyarimwe, HF - 365FR ifasha kugabanya itandukaniro ryuburebure, impande zingana, gutunganya ibikoresho, hamwe nuwabikora - amakosa ashingiye. Kwiyongera - uburebure bwa porogaramu, kubika amakuru yumusaruro, no guhagarara - no gusubiramo imirimo bituma bikenerwa cyane mugutegura umuringa na aluminium mbere yo gusudira byoroshye.
Impamvu Umusaruro woroshye wa Busbar usaba imashini yihariye yo gukata
Ifu y'umuringa na aluminiyumu iroroshye, yoroshye, kandi ihindagurika byoroshye. Niba kugaburira, gufata ibintu - hasi, cyangwa gukuraho icyuma ntibihamye, ibibazo byinshi bishobora kubaho:
- Uburebure bwa file budahuye bubuza ibice guhuza neza;
- Iminkanyari, yunamye, cyangwa yatemaguwe;
- Ibikoresho bigenda mugihe cyo kugaburira, bikavamo gukata inguni;
- Umusaruro muke mugihe imizingo igomba gutunganywa kugiti cye;
- Ibisigazwa by'inyongera nyuma yo guhagarika cyangwa gutangira umusaruro;
- Kuvanga ibikoresho - hejuru iyo uburebure butandukanye butandukanijwe nintoki.
HF - 365FR ihuza umuzingo utabishaka, kuyobora, kugaburira servo, gufunga ibikoresho, no guca - kugeza - gutunganya uburebure. Iyo imizingo imaze kwipakurura hamwe nibipimo byumusaruro byinjijwe, imashini irangiza gukata byikora mu buryo bwikora, bigabanya gupima intoki inshuro nyinshi no guhinduranya ibikorwa.
Ibikoresho bikwiranye na HF-365FR
Imashini yabugenewe cyane cyane kumusaraba - gukata ibyuma bito bitangwa mumuzingo. Ibikoresho bisanzwe birimo:
- Umuringa wuzuye umuringa;
- Amabati - yometseho umuringa;
- Aluminium;
- Umuringa muto;
- Inzira ya aluminiyumu;
- Impapuro zikoreshwa mumashanyarazi yoroheje;
- Ibindi byuma byoroheje bifite ubugari bwagaragaye kandi bukomeye.
Uburebure bwibikoresho bisanzwe ni 0,01-0.3 mm, hamwe nubugari bukomeye bwa mm 1-365. Niba ibikoresho bifite igipfundikizo, firime ikingira, igipande gifatika, cyangwa ubukana burenze ubw'umuringa usanzwe cyangwa aluminiyumu, gukata icyitegererezo birasabwa mbere yuko imashini irangira.
HF {1 Porogaramu hanze yubugari busanzwe, ubugari, cyangwa ubukana bisaba isuzuma ryihariye ryicyuma, uburyo bwo gufata hasi, sisitemu yo kugaburira, hamwe nimashini.
Ibisanzwe
Gutegura Umuringa wo Gutegura Busbars zihinduka
Umuringa woroshye wa busbars ukorwa muburyo bwo gutondekanya ibice byinshi byumuringa muto kandi ugahuza impande zombi binyuze mu gusudira, gusudira, cyangwa ubundi buryo bukwiye. Uburebure nuruhande rwa buri fayili bigira ingaruka kumurongo, guhagarara, kwikuramo, no gusudira.
HF - 365FR ikata feza y'umuringa ubudahwema ukurikije uburebure bwateganijwe hamwe nubunini bwayo, itanga ibikoresho bihamye byo gutondekanya ibice, guhuza impera, no gusudira. Igishushanyo cyacyo cya sitasiyo enye nacyo kigabanya igihe cyo gutinda kijyanye no guca imizingo myinshi ukwayo.
Aluminium Foil Gutegura Guhuza Byoroshye
Ifu ya aluminiyumu iroroshye kandi irashobora kubyimba byoroshye cyangwa kuva mumwanya mugihe cyo kugaburira. Gukomatanya kuyobora bishobora guhindurwa, ibikoresho bifata - hasi, hamwe no kugaburira servo bifasha kugumisha fayili neza mbere yuko igera kumurongo.
Mbere yumusaruro wicyiciro, gukata byintangarugero bigomba gukorwa ukurikije uburebure bwa file, imiterere yubuso, impagarara zingana, hamwe nuburebure bwintego. Umuvuduko wo kugaburira no gufata - hasi igenamiterere rirashobora guhinduka kugirango rihuze ibikoresho.
Amashanyarazi ahuza
Muri bateri no kubika ingufu zikoreshwa, umuringa wa laminate cyangwa aluminiyumu isanzwe inyura mubikorwa byinshi, harimo gukata - kugeza - gutegura uburebure, gutondeka, kwikuramo, gusudira, gukubita, no gukora.
HF-365FR irashobora gushyirwaho mugitangira cyumurongo uhuza imiyoboro ihuza kandi igahuzwa hamwe na fayili yo hasi, gusudira gukwirakwiza, gukubita, no kurangiza ibikoresho.
Ibikoresho byo gukwirakwiza amashanyarazi nimbaraga
Imashini irashobora kandi gutegura imirongo yoroheje y'umuringa na aluminiyumu ikoreshwa muri switchgear, transformateur, ibikoresho byo gukwirakwiza, hamwe na electronics power. Ibipimo byumusaruro kubice byakorewe kenshi birashobora kubikwa cyangwa re - byinjiye vuba, kugabanya igihe cyo gushiraho mugihe uhinduranya ibisobanuro.
Imikorere nyamukuru n'ibishushanyo biranga
Igenzura rya PLC na Touchscreen
Umukoresha arashobora gushiraho uburebure bwo kugabanya, ingano yumusaruro, n'umuvuduko wo gukora ukoresheje ecran ya ecran. Kugenzura ibipimo byibanze bituma igeragezwa rikorwa, guhindura ibicuruzwa, hamwe nibicuruzwa byoroshye kuyobora.
Imashini ihagarara mu buryo bwikora mugihe ingano yateganijwe yarangiye, kugabanya amakosa yo kubara no kwirinda umusaruro udakenewe.
Servo - Gukata Igenzura - kugeza - Kugaburira Uburebure
Moteri ya servo na drive bigenzura uburebure bwibiryo binyuze muri gahunda ya PLC. Sisitemu ikwiranye no kongera umusaruro wuburebure butandukanye kuruta gupima intoki cyangwa guhagarara.
Kwihanganira gukata bisanzwe ni ± 0,05 mm. Ibisubizo nyabyo birashobora gutandukana bitewe nubunini bwa file, impagarara zingana, imiterere yubuso, umuvuduko wo kugaburira, nuburebure bwa gahunda.
Guhindura Ibikoresho
Imiyoboro yicyuma irashobora guhindurwa kugirango ihuze ubugari bwibintu bitandukanye kandi igumane ifoto ihujwe nkuko yinjira mubice byo kugaburira no gukata.
Nyuma yo guhindura imizingo, icyerekezo cyo kuyobora kigomba kugenzurwa. Kurenza urugero birashobora kwemerera ibikoresho kugenda, mugihe ibihagije bidahagije bishobora kwangiza impande zombi cyangwa kongera imbaraga zo kugaburira.
Guhuza Ibikoresho Guhuza no Gukata
Gufata uburyo bwihariye - hasi bikingira ibikoresho mbere yuko icyuma kigenda, bikagabanya amahirwe yo guhinduranya cyangwa guhindagurika mugihe cyo gutema.
Gukata icyuma bikozwe mubyuma bivanze kandi neza - hasi. Gukosora neza icyuma, igitutu cyo gufunga, hamwe nigihe cyo kubungabunga bifasha kugumana isuku mugihe ugabanya burrs nimpande zigoramye.
Imiterere yimashini ikomeye
Icyuma gifata ibyuma hamwe nimashini nyamukuru ikoresha igishushanyo mbonera cyubatswe, hamwe nibyuma byibyuma bitanga ubukana muri buri cyiciro.
Ikadiri ihamye ifasha kugabanya gutandukana guterwa no kunyeganyega cyangwa guhindura imiterere mugihe kirekire - mikorere.
Ubukonje bwo Gukomeza Gukora
Abafana bakonje bifasha kugenzura ubushyuhe bwamashanyarazi no gutwara ibice mugihe kinini cyo gukora. Umuyaga uhagije ugomba kubungabungwa hafi yimashini, kandi umukungugu ugomba kuvanwa buri gihe mubafana, muyungurura, no mumashanyarazi.
Ibicuruzwa bisobanura
|
Ibigize |
Ikirango |
Inkomoko |
|
Gukoraho Mugaragaza |
Kunlun Tongtai (MCGS) |
Ubushinwa |
|
PLC |
Mitsubishi |
Ubuyapani |
|
Moteri ya AC |
Kugabanya |
Tayiwani, Ubushinwa |
|
Gukata Icyuma |
Daido |
Ubuyapani |
|
Umushoferi wa Servo |
Tonghang |
Ubushinwa |
|
Motor Motor |
Tonghang |
Ubushinwa |
|
Ikiruhuko |
Schneider |
Ubufaransa |
Ibikoresho byamashanyarazi nuburyo bwimashini birashobora kuvugururwa murwego rwo gukomeza iterambere ryibicuruzwa. Iboneza ryanyuma rigengwa namasezerano ya tekiniki hamwe namabwiriza yatanzwe byemejwe nimpande zombi.
Ibisobanuro bya tekiniki
|
Parameter |
Ibisobanuro |
|
Icyitegererezo |
HF-365FR |
|
Gukata Uburebure |
1 - 9999.9 mm |
|
Gukata Ubugari |
1 – 365mm |
|
Gukata neza |
1 – 1200pcs / min (Birashobora guhinduka) |
|
Gukata neza |
± 0,05 mm |
|
Gukata Ubunini |
0.01 – 0.3mm |
|
Icyiza. Umutwaro Wibikoresho |
50 kg (Umurongo umwe) |
|
Ibikoresho by'imbere |
74-79mm |
|
Imbaraga zose |
3.6kW |
|
Umuvuduko |
220V |
|
Ibiro |
380kg |
|
Ibipimo (L × W × H) |
2500 × 1000 × 1200 mm |
Igipimo cyo kugabanya ni igipimo gishobora gukoreshwa cyimashini kandi ntabwo bivuze ko umusaruro mwinshi ushobora kugerwaho hamwe nibikoresho byose cyangwa uburebure. Umuvuduko nyawo wo guterwa biterwa nuburebure bwa file, ubugari, ubugari, umubare wimizingo itunganywa, nuburyo bwo gukusanya ibikoresho.
Ibibazo byumusaruro HF-365FR Ifasha Aderesi
Uburebure budahuye buterwa no gupima intoki
Servo - kugaburira kugenzurwa bituma imashini isubiramo uburebure bwateganijwe bwo kugabanya, kugabanya itandukaniro rinini rijyanye no gupima kaseti, guhagarika intoki, cyangwa guca urubanza.
01
Guhuza Kubi Byerekeranye na Foil Layers
Uburebure bwa foil burebure butuma gutondeka no kurangiza byoroshye. Kubigoramye byoroshye guhuza, kwiyongera - gahunda ndende irashobora gutanga indishyi zikenewe hagati yinzego.
02
Igihe cyatakaye mugihe cyo gutunganya imizingo kugiti cyawe
Sitasiyo enye zifasha imizingo myinshi gupakirwa no gutunganyirizwa murwego rumwe rwo gukora, bikanoza imikorere yo gutegura umuringa wacuzwe na aluminiyumu byoroshye.
03
Imyanda y'ibikoresho nyuma yo guhagarika umusaruro
Kuruhuka kurinda no kubika amakuru bifasha imashini gusubukura aho ikwiye, kugabanya imyanda yo kugaburirwa inshuro nyinshi, kubara, no kugabanya gushiraho.
04
Gutegura ibikoresho bidahwitse mbere yo gusudira
Uburebure bwa fayili ihoraho, gukata ubuziranenge, hamwe nuburinganire bitanga urufatiro rwizewe rwo gukurikiraho, gufunga, gusudira, no gukubita. Nubwo imashini ikata itagaragaza ubwiza bwa nyuma bwo gusudira ubwayo, igabanya ibibazo byimyanya iterwa no kwitegura neza.
05
Kuki Hitamo HAIFEI
HAIFEI itanga ibirenze imashini zogosha umuringa. Ubunararibonye bwacu bukubiyemo kandi ibikoresho bya bisi ya buringa ya aluminium na aluminiyumu, imiyoboro iyobora imiyoboro, amabisi akomeye, nibindi bikoresho bikoreshwa mumashanyarazi ningufu nshya.
Mugihe duhitamo imashini, injeniyeri zacu zitekereza uburyo inzira yo gukata igira ingaruka kumurongo hamwe no gusudira. Uburebure bwa fayili, umubare wibice, uburyo bwo gutondekanya, ahantu ho gusudira, no kurangiza - igice cya geometrie bisubirwamo hamwe aho guhitamo imashini kubugari bwibintu gusa.
Inkunga iboneka y'umushinga ikubiyemo:
- Gusubiramo gusaba gushingiye kubisobanuro bifatika n'ibishushanyo mbonera;
- Gukata igeragezwa ry'umuringa na aluminiyumu;
- Isuzuma ryiyongera - gahunda ndende;
- Guhuza nibikoresho byo gusudira byo hasi;
- Guhindura ibicuruzwa bidasanzwe, kuyobora ibikoresho, hamwe na sisitemu yo gukusanya;
- Mbere - kugerageza imashini yoherejwe no kwemeza icyitegererezo;
- Kwishyiriraho, gukora, no kuyobora;
- Shira icyuma kandi wambare - ibyifuzo byigice.
Impamyabumenyi
Twakoreye abakiriya barenga 5, 000+ ku isi hose, kandi abafatanyabikorwa bacu maremare - barimo Tesla, BYD, na Siemens.
Kurenga 50+ Amahirwe 500 ibigo.
Abafatanyabikorwa bacu
{0}
Urubuga rwabakiriya
Ibibazo
Ikibazo: HF-365FR irashobora guca imizingo ine yumuringa icyarimwe?
Igisubizo: Yego. Imashini ifite sitasiyo enye zidashaka kandi irashobora gutunganya imizingo igera kuri ine mugihe kimwe cyo gukata. Ubugari bwa muzingo, uburemere, na gahunda bigomba kuguma mubushobozi bwimashini.
Ikibazo: Iyi mashini irashobora guca feza ya aluminium?
Igisubizo: Yego. HF - 365FR ibereye umuringa usanzwe na aluminium. Kubera ko aluminiyumu yoroheje yoroshye, gukata ibigeragezo birasabwa gushiraho umuvuduko ukwiye wo kugaburira, kuyobora neza, hamwe no gufata-hasi.
Ikibazo: Ni ubuhe buryo busanzwe buringaniye?
Igisubizo: Uburebure busanzwe ni 0.01–0.3 mm. Ibikoresho hanze yuru rwego bisaba isuzuma ryihariye ryicyuma, uburyo bwo kugaburira, nimiterere yimashini.
Ikibazo: Imashini irashobora guca fayili muburebure butandukanye?
Igisubizo: Yego. Gukata uburebure nubunini birashobora gutegurwa ukoresheje ecran ya ecran. Kwiyongera - gukata birebire nabyo birahari kubihuza byoroshye bisaba indishyi ndende hagati yinzego.
Ikibazo: Ni ubuhe buryo bwo kwihanganira kugabanya HF-365FR ishobora kugeraho?
Igisubizo: Kwihanganira gukata bisanzwe ni ± 0,05 mm. Ibisubizo nyabyo biterwa nubunini bwa file, guhagarika umuzingo, imiterere yubuso, kugaburira umuvuduko, no kugabanya uburebure.
Ikibazo: Ese ifu y'umuringa yaciwe izaba ifite burrs?
Igisubizo: Imashini ikoresha ibikoresho bifata - uburyo bwo hasi hamwe nuruvange - icyuma cyo gukata ibyuma kugirango bitange inkombe isukuye neza iyo ihinduwe neza. Kwambara inkota, gusiba nabi, cyangwa ibikoresho bidasanzwe birashobora kugira ingaruka kumiterere, bityo rero birasabwa kugenzura no kubungabunga buri gihe.
